Comau Racer 3

Industrial 6 axis robot.

The Comau Racer 3 robot is a 6-axis robotic arm, offering a payload of 3.0 kg and a reach of 630 mm. The repeatability of the Comau Racer 3 robot is 0.02 mm. Common applications of the Comau Racer 3 robot include: arc welding, dispensing, remote tcp, assembly, etc.

Number of axes - 6

Maximum wrist payload (kg) - 3

Additional load on the forearm (kg) - 2

Maximum horizontal reach (mm) - 630

Torque on axis 4 (Nm) - 7.36

Torque on axis 5 (Nm) - 7.36

Torque on axis 6 (Nm) - 4.41

Repeatability (mm) +- 0.02

Tool coupling flange ISO 9409 – 1 – A 40

Robot weight (kg) - 30

Protection class IP54

Mounting position Floor / Ceiling / Inclined / Wall
